Accessories
FIC - Nex•U•® Fluid Monitoring System
NEX·U·®
U·POWER & U·POWER+
Models Available :
3110-106
U·power+. Power supply unit with a 320 W transformer for use with 8 solenoid valves. Two CAN BUS
ports (one input/one output)
3110-108
U·power. Power supply unit with a 75 W transformer for use with 2 solenoid valves. Two CAN BUS ports
(one input/one output)
3110-146
U·power+. Power supply unit with a 320 W transformer for use with 8 solenoid valves. Three CAN BUS
ports (one input/two output)
Can Bus to WiFi Converter
Models Available :
3110-145
Allows wireless communication among the different components of the system. Equipped with an
external antenna, it allows for extended signal coverage. It can be configured from a Windows or
Android application. Can be used with any CAN BUS component
Bluetooth Printer
Models Available :
3110-109
Optional printer for use with NEX·U·® COMPACT, connected via Bluetooth to the U·dat.
Barcode
Models Available :
3110-140
Bar code laser reader. Reads any one dimensional code. For use with a U·dat, U·dat Power+ and U·dat
for NEX·U·® mobile and compact systems.
U•VALVE Bracket
Models Available :
2230-040
Allow for mounting U·valve on top of a hose reel stand.
Can Bus Cable
Models Available :
3130-110
100’ (30.5 m) CAN BUS communication cable
3130-500
500’ (152.4 m) CAN BUS communication cable
3130-100
1,000’ (304 m) CAN BUS communication cable
3110-143
Jumper cable. 1.6’ (0.5 m) cable with pre-wired connectors 3110-141 for connecting adjacent elements with a CAN BUS cable
3110-141
In/out electrical connectors. For use with U·meter, U·meter+
3110-136
Allows wiring connection between U·valves
Level Gauges
Models Available :
3120-084
Tank level pressure gauge. Allows real-time monitoring of the volume in a tank. Maximum tank depth 11 1/2” (350 cm)
3120-079
Digital level gauge. Detects minimum, intermediate or maximum volume in a tank. Does not allow real-time monitoring. Adjustable height, includes 16’ (5 m) cable
3120-029
Remote flash and acoustic alarm
Solenide Valves for Fluids
Models Available :
3120-217
Oil and antifreeze solutions. Brass and NBR
Pressure: 725 PSI (50 bar)
Connection: 1/2″ NPT (F/F)
Power: 24 V DC
Director Jr.
Fluids: Motor oils, Synthetics, ATF, Gear oils, and Anti-freeze (Glycol)
Pressure: 3045 PSI (210 bar)
Connection: 1/2″ NPT(F)
Power: 24 V AC/DC
3120-226
DEF; antifreeze and windshield wash solutions, stainless steel and EPDM
Pressure: 145 PSI (10 bar)
Connection: 1/2″ NPT (F/F)
Power: 24 V DC
Solenoid Valves for Compressed Air – Pump Control
Models Available :
3120-033
Compressed air. Brass and NBR
Pressure: 145 PSI (10 bar)
Connection: 1/2″ NPT (F/F)
Power: 24 V AC
Director Jr.
Pressure: 200 PSI (12 bar)
Connection: 3/8″ NPT (F/F)
Power: 24 V DC
3120-225
Compressed air. Brass and NBR
Pressure: 145 PSI (10 bar)
Connection: 1/2″ NPT (F/F)
Power: 24 V DC
